The London-based fruit shop, Fresh Fruit Ltd. needs RPA’s help for their fruit sales.

What you will learn

  • Primarily:
    • The most common variable types: Text, Number and List
    • Flow variables
  • Secondarily:
    • Basic Power Automate activities
    • Input/output variables

Client Name

Fresh Fruit Ltd.

Process Name



Fresh Fruit Ltd. wants to automate the process for creating a fruit sale, and you’re in charge of creating an attended robot that can take user input, process the user data, and output it:

  • Text
  • Use a Display message with the text ‘On sale this week: Apple’
  • Use the Set variable to create a text variable called %Fruit% with the value ‘Banana’
    • Replace the ‘Apple’ in the Place Message with your newly created variable, %Fruit%
  • Run the flow and inspect the Flow variables to the right
  • Use a Display input dialog to take user input. The title should be ‘Type in the fruit on sale; the Input dialog message should be ‘Type in the fruit on sale’
    • Inspect the output variables produced
    • Delete the Set variable
    • Fix the output variable in the Display input dialog
  • Advanced:
    • Inspect the ButtonPressed2 produced variable in the Input Dialog. Rename it to a more describing name. Use it in an If action to only make the flow run when the user clicks ‘Ok’ and not ‘Cancel’
  • Number
  • Use a Set variable (after Display input dialog)
    • Rename it to Price
    • Value: 2.6
  • Correct the Display message to, Name: Only TODAY: %Fruit% is sold at %Price%
  • Run and inspect the Flow variables (Text and Number)
  • Replace the Set variable with another Display input dialog
    • Fix the title, message, and produced output variable
  • Advanced:
    • What if the user clicks ‘Cancel’ in the last Display input dialog?
    • Fix: Change the If condition and put inside % % and set it to equals to %True%
  • Use the Truncate number to
    • Get the integer part, problem?
    • Round the number, 0 decimals
  • List
  • Use a Create new list and give it the name ‘Vegetables’
  • Use the Add item two times to add to items to the list (Potato and Onion)
  • Use a For each with a Display message in to display the items of the list
    • CurrentItem should be renamed to say something about the individual variable (try Vegetable)
  • Advanced:
    • Add more items to the list with a Set variable and the value %[‘Beets’, ‘Carrots’, ‘Spinach’]%

Video Guide
